5+3 Surgical Operating Lamp

The common type 5+3 Surgical Operating Lamp use true cold light source,features a petal-shaped three-dimensional design with multiple light sources, making the light spot illumination more uniform.

Category Double head surgical light

Description
Parameter

Product description:

The common type 5+3 Surgical Operating Lamp use true cold light source,features a petal-shaped three-dimensional design with multiple light sources, making the light spot illumination more uniform.Uses computer-aided modular design with multiple LED light columns focusing to produce depth illumination of over 1200 millimeters.Equipt a liquid crystal display key control, allowing for adjustments of power switch, illumination, color temperature, etc., to meet the requirements of medical staff for different patients’surgical brightness.

Technical parameters	LED700	LED500
Illuminance (adjustable)	40,000-160,000Lux	30,000-160,000Lux
Number of light sources	61颗	39颗
Lamp type	LED	LED
Average life of lamp	≥80，000h	≥80，000h
Color temperature (adjustable)	3700K ～5000K	3700K ～5000K
Display index (adjustable)	85～98	85～98
Focus depth	50-180cm	50-180cm
Spot diameter	120-300mm	120-300mm
Brightness adjustment	1%-100%	1%-100%
Power consumption (W)	65	40
Head temperature of operator	﹤1℃	﹤1℃
Power supply voltage	AC100-240V 50/60HZ	AC100-240V 50/60HZ
